Technical tools for specifying, calculating, and documenting glass installations in Singapore. Load tables, BCA compliance references, engineering calculators, and submission documentation support.
Engineering Resources
Technical tools and specifications for specifying glass in your projects. All calculators are free to use and based on published engineering methods with full citations.
Glass Interlayer Calculator
Compare PVB vs SGP interlayer performance for laminated glass. Based on the Wölfel–Bennison equivalent thickness method and ASTM E1300.
Acoustic Glazing Specs
STC ratings, Rw values, U-values, and cost-per-m² for five standard configurations plus two high-performance upgrades.
BCA Compliance Docs
Access our library of BCA submission documents, test certificates, and structural calculation reports for completed projects.
BCA Compliance Standards
Our installations are specified to comply with relevant Singapore Standards and BCA requirements for each project type. Below are the key standards applicable to architectural glazing.
SS EN 12150-1
Thermally Treated Toughened GlassSpecifies requirements for flat, thermally toughened soda lime silicate safety glass for building use.
Our application: All our tempered glass installations comply with this standard for impact resistance and fragmentation.
SS EN 14449
Laminated GlassRequirements for laminated glass and laminated safety glass for building use.
Our application: PVB and SGP laminated glass installations meet structural and post-breakage safety criteria.
SS EN 16612
Load Resistance of Glass PanesDetermination of the load resistance of glass panes by calculation and testing.
Our application: Structural calculations for balustrades, overhead glazing, and large span installations.
SS EN 1991-1-4
Wind Actions (Singapore Annex)General actions — wind actions with Singapore National Annex.
Our application: Wind load calculations for high-rise glazing, façade engineering, and balcony installations.
SS 508:2013
Glass for Windows & DoorsSpecification for glass in building — windows and doors.
Our application: Minimum glass thickness, safety requirements, and marking specifications for residential glazing.
SS 501
Green Mark — Façade EnvelopeBCA Green Mark criteria for building envelope thermal and daylight performance.
Our application: IGU U-value and SHGC specifications for energy-efficient building compliance.
Glass Load Tables
Maximum recommended pane sizes for common glass configurations under different design loads. Values are based on SS EN 16612 and ASTM E1300 for simply-supported rectangular plates.
| Configuration | 1.0 kPa (mm × mm) | 1.5 kPa (mm × mm) | 2.0 kPa (mm × mm) | Typical Application |
|---|---|---|---|---|
6mm Tempered | 1200 × 1800 | 900 × 1400 | 800 × 1200 | Standard windows, internal partitions |
8mm Tempered | 1600 × 2400 | 1200 × 1800 | 1000 × 1500 | Large windows, balcony doors |
10mm Tempered | 2000 × 3000 | 1500 × 2200 | 1200 × 1800 | Shower screens, frameless doors |
12mm Tempered | 2400 × 3600 | 1800 × 2600 | 1500 × 2200 | Glass floors, balustrades, large façades |
6+1.52PVB+6 Laminated | 1400 × 2000 | 1100 × 1600 | 900 × 1400 | Overhead glazing, safety balustrades |
6+1.52SGP+6 Laminated | 2200 × 3200 | 1800 × 2600 | 1500 × 2200 | Structural fins, canopies, frameless balustrades |
Values assume simply-supported edges, tempered glass with characteristic strength f_k = 120 MPa, and safety factor ≥ 2.5. For project-specific calculations, use ourGlass Interlayer Calculatoror contact our engineering team.
Singapore Wind Pressure Zones
Design wind pressures per SS EN 1991-1-4 Singapore National Annex for different building heights and exposure zones. Use these values in our calculator or your own structural analysis.
| Building Height | Zone A (Open) | Zone B (Suburban) | Zone C (Urban) | Zone D (CBD) |
|---|---|---|---|---|
| ≤ 10m | 1.00 kPa | 1.15 kPa | 1.30 kPa | 1.45 kPa |
| 10 – 20m | 1.15 kPa | 1.30 kPa | 1.50 kPa | 1.65 kPa |
| 20 – 30m | 1.30 kPa | 1.50 kPa | 1.70 kPa | 1.85 kPa |
| 30 – 50m | 1.45 kPa | 1.65 kPa | 1.85 kPa | 2.00 kPa |
| 50 – 100m | 1.65 kPa | 1.85 kPa | 2.05 kPa | 2.20 kPa |
| > 100m | 1.85 kPa | 2.05 kPa | 2.25 kPa | 2.40 kPa |
These are simplified values for preliminary design. Final submissions require site-specific wind tunnel data or detailed SS EN 1991-1-4 calculations with terrain category, building shape, and dynamic response factors. Our engineering team provides certified calculations for BCA submissions.
BCA Submission Services
We provide full documentation support for BCA submissions, including structural calculations, test certificates, and method statements.
Structural Calculation Reports
Certified load resistance calculations per SS EN 16612 for wind, impact, and dead loads.
Glass Test Certificates
Third-party laboratory certificates for tempered, laminated, and IGU glass compliance.
Installation Method Statements
Detailed step-by-step installation procedures with safety protocols and quality checkpoints.
Green Mark Documentation
Thermal performance calculations, daylight analysis, and façade envelope submissions.
Need Technical Documentation?
Our engineering team provides project-specific calculations, test certificates, and BCA submission documentation. Contact us for a consultation.
